Ortho48 Keyboard Kit

Regular price
Sold Out
Sale price

When I first joined the Mech Keys community, I really wanted to try out an ortholinear board. But the prices were just too expensive! It was $70 for an item I wasn't sure I would like.

This is my solution to that problem - the Ortho48.

The Ortho48 is a 12x4 ortholinear keyboard kit, similar to other offerings. It has almost everything you need to build out a keyboard- just add switches and keycaps!

The board also supports RGB underglow, per-key LED backlighting with south facing LEDs, and is powered by an STM32 Blue Pill board running QMK. It is fully programmable with QMK, and can be flashed with dfu-util.

The Ortho48 kit comes with:

  • 1 Ortho48 PCB
  • 1 Ortho48 Plate Set (top and bottom)
  • 1 STM32 based Blue Pill
  • 48 diodes
  • 48 resistors
  • 1 USB Mini Port
  • 1 MOSFET
  • 1 Resistor for MOSFET
  • 1 Right angle reset switch
  • 10 M2 screws
  • 5 15mm M2 standoffs

Note: As of May 2020, this kit no longer includes the USBLC6-4SC6 ESD protection chip, as most customers did not use it. You can source it at DigiKey, Mouser, or any other local electronics suppliers.

The Ortho48 has 19.05mm spacing, and is compatible with any cases that support it, such as the jj40 from KPRepublic.

You will need some tools to put the kit together. There is a full build guide available on our documentation site.
